Super Powered Canon EOS C700 FF Full-Frame Cinema Camera – Specs, Features & Review
Canon EOS C700 FF Features & Review
The Canon EOS C700 FF stands as Canon’s flagship full-frame digital cinema camera, meticulously crafted for high-end film and television production. With its advanced imaging capabilities, modular design, and versatile recording options, it caters to the demanding needs of professional cinematographers.
Full Specifications of Canon EOS C700 FF
Sensor
- Type: Full-frame CMOS sensor
- Size: 38.1 x 20.1 mm
- Resolution: 5952 x 3140 pixels (5.9K)
- Dynamic Range: Over 15 stops with Canon Log 2
- Sensor Modes: Full Frame, Super 35mm (Crop), Super 16mm (Crop)(global.canon, canon.com.cy, canon.com.cy)
Image Processor
- Processor: Triple DIGIC DV 5(canon.com.cy)
Lens Mount
- Options: Canon EF mount with Cinema Lock or PL mount (Cooke /i Technology compatible)
- Compatibility: Supports anamorphic lenses and B4 mount lenses via adapter(canon.com.cy)
Recording Formats
- RAW Recording: 5.9K RAW up to 60 fps with optional Codex CDX-36150 recorder
- Internal Recording:
- XF-AVC up to 4K at 810 Mbps
- Apple ProRes 422 HQ up to 4K UHD at 30p
- Proxy Recording: 2K/HD proxy files to SD card(cinemaeos.canon.ca, canon.com.mt, asia.canon, canon.com.cy)
Frame Rates
- 5.9K RAW: Up to 60 fps
- 4K (Crop): Up to 72 fps
- 2K (Crop): Up to 168 fps(canon.ca, photographyblog.com)
Built-in ND Filters
- Stops: 2, 4, 6, 8, and 10 stops(lemac.com.au)
Autofocus
- System: Dual Pixel CMOS AF (EF mount only)
- Features: Accurate, reliable, and smooth autofocus with Dual Pixel Focus Guide(shop.cinneshop.com, canon.com.mt)
Connectivity
- Video Outputs: 2x BNC (3G-SDI), 4x BNC (3G-SDI), 1x HDMI
- Audio Inputs: 2x XLR 3-Pin Microphone Inputs, 1x 3.5 mm Stereo Headphone Output
- Power Inputs: 1x XLR 4-Pin (12VDC), 1x D-Tap (12 to 24VDC at 2 A)
- Other I/O: Timecode, Genlock, RJ45 for IP streaming(bhphotovideo.com)
Media
- Slots: Dual CFast 2.0 card slots, Single SD/SDHC/SDXC card slot(bhphotovideo.com)
Dimensions and Weight
- Dimensions: 6.6 x 6.1 x 12.9 inches (16.7 x 15.4 x 32.7 cm)
- Weight: 7.6 lb (3.4 kg)(bhphotovideo.com)
Description
The Canon EOS C700 FF is engineered for professionals seeking top-tier performance in digital cinematography. Its full-frame 5.9K CMOS sensor delivers exceptional image quality with a wide dynamic range, making it ideal for high-resolution productions.
The camera’s modular design allows for versatile configurations, accommodating various shooting styles, from handheld to studio setups. With support for multiple recording formats, including RAW, ProRes, and XF-AVC, it integrates seamlessly into diverse workflows. (cinemaeos.canon.ca)
Dual Pixel CMOS AF ensures precise and smooth autofocus, enhancing shooting efficiency, especially in dynamic environments. The inclusion of built-in ND filters and support for anamorphic lenses further expands creative possibilities.(canon.com.cy, lemac.com.au)
Connectivity options like SDI, HDMI, and IP streaming capabilities make the EOS C700 FF a comprehensive tool for modern cinematography demands.(canon.com.mt)
Pros and Cons
Pros:
- High-resolution 5.9K full-frame sensor
- Wide dynamic range exceeding 15 stops
- Versatile recording formats and frame rates
- Modular design for flexible configurations
- Dual Pixel CMOS AF for accurate autofocus
- Built-in ND filters for exposure control
- Comprehensive connectivity options(asia.canon, canon.com.cy)
Cons:
- High cost, making it more suitable for large-scale productions
- Requires additional accessories (e.g., Codex recorder) for full capabilities
- Complexity may present a learning curve for new users( Asia.Canon )
Related Products
Canon EOS C300 Mark III is a great alternative of Canon EOS C700 FF
The Canon EOS C300 Mark III is a professional Super 35mm digital cinema camera built for serious filmmakers and content creators. At the heart of this powerhouse is Canon’s revolutionary 4K Super 35mm DGO (Dual Gain Output) sensor, delivering over 16 stops of dynamic range for stunning highlights and deep shadows in every frame.
It supports internal 4K Cinema RAW Light and XF-AVC recording up to 120 fps in 4K and 180 fps in 2K (cropped). With multiple codec options and frame rates, it’s perfect for high-end productions, documentaries, commercials, and more. The camera uses Canon’s modular design, making it adaptable for handheld shooting, gimbal setups, or full cinema rigs.
It features an EF lens mount (PL mount version also available), Dual Pixel CMOS AF with intelligent tracking, and built-in ND filters (2/4/6/8/10 stops). Dual CFexpress card slots, timecode, genlock, and SDI outputs ensure seamless integration into any production environment.
The EOS C300 Mark III combines top-tier image quality with workflow flexibility, all in a compact, lightweight body – ideal for productions where agility and cinematic excellence are both must-haves. Whether you’re shooting indie films or Netflix-grade content, this camera delivers.
Check Price on Amazon
Canon EOS C500 Mark II is also an alternative to Canon EOS C700 FF
The Canon EOS C500 Mark II is a powerful full-frame digital cinema camera designed for professional filmmakers who demand high-end performance with flexible workflows. It features a 5.9K full-frame CMOS sensor that delivers exceptional image quality with rich colors and over 15 stops of dynamic range – ideal for cinematic productions.
Equipped with Canon’s DIGIC DV 7 processor, the C500 Mark II supports internal 5.9K Cinema RAW Light recording at up to 60 fps and 4K 10-bit 4:2:2 XF-AVC recording to dual CFexpress cards, enabling efficient post-production without compromising quality. It also supports proxy recording to SD cards and simultaneous outputs via 12 G-SDI and HDMI.
The modular body design includes interchangeable lens mounts (EF by default, with optional PL and B4), allowing for flexible lens choices. Dual Pixel CMOS AF provides accurate and smooth autofocus with touchscreen control, making it ideal for both handheld and gimbal use.
With built-in ND filters (2/4/6/8/10 stops), Canon Log 2 and 3, anamorphic support, and full-frame/S35mm crop modes, the Canon EOS C500 Mark II is a versatile cinema camera perfect for narrative film, commercials, and documentary projects.
Check Price on Amazon
Canon EOS R5 C is also an alternative to Canon EOS C700 FF
The Canon EOS R5 C is a hybrid full-frame mirrorless cinema camera that bridges the gap between high-resolution photography and professional-grade filmmaking. Designed for creators who demand versatility, it combines the core features of the EOS R5 with advanced video capabilities from Canon’s Cinema EOS line.
At its heart is a 45MP full-frame CMOS sensor paired with the DIGIC X processor, enabling stunning stills and internal 8K 60p RAW video recording. It supports Cinema RAW Light, XF-AVC, and MP4 formats, with 4K and Full HD options at various frame rates, including slow motion at up to 120fps in 4K. Dual Pixel CMOS AF II with Eye and Face Detection ensures precise focus in both photo and video modes.
The R5 C features an active cooling fan, allowing extended 8K recording without overheating, and offers Timecode I/O, 3.5mm mic/headphone jacks, and a multi-function shoe for pro audio input. Dual card slots (CFexpress and SD UHS-II) ensure flexible media management.
With a compact, lightweight build, a fully articulating touchscreen, and Canon Log 3 for greater dynamic range, the Canon EOS R5 C is ideal for filmmakers, YouTubers, and hybrid content creators demanding high performance in a portable package.
Canon EOS C200 is also an alternative to Canon EOS C700 FF
The Canon EOS C200 is a professional-grade digital cinema camera designed for filmmakers, YouTubers, and content creators seeking high-end performance in a compact form. It features a Super 35mm CMOS sensor capable of recording 4K DCI (4096 x 2160) resolution, delivering stunning image quality with rich detail and dynamic range.
One of the standout features of the C200 is its ability to capture Cinema RAW Light internally to CFast 2.0 cards, offering powerful post-production flexibility without massive file sizes. It also supports MP4 recording to SD cards for faster workflows. With Dual Pixel CMOS Autofocus (DPAF), the camera ensures smooth, accurate, and reliable focus tracking – even in challenging conditions.
The C200 includes built-in ND filters (2, 4, 6, 8, 10 stops), two XLR inputs for professional audio, and a rotating 4” touchscreen LCD monitor. It offers high frame rate recording up to 120 fps in Full HD and seamless integration with Canon’s EF lens ecosystem.
Compact, lightweight, and versatile, the Canon EOS C200 is perfect for indie filmmaking, documentaries, and corporate shoots, balancing advanced features with intuitive controls and flexibility.
Canon EOS C100 Mark II is also an alternative to Canon EOS C700 FF
The Canon EOS C100 Mark II is a professional Super 35mm digital cinema camera designed for filmmakers, documentarians, and content creators who demand exceptional image quality in a compact form. Equipped with a Super 35mm CMOS sensor and Dual Pixel CMOS AF, it delivers sharp, cinematic visuals with smooth and reliable autofocus – ideal for solo shooters and small crews.
This camera supports Full HD recording (1920×1080) in both AVCHD and MP4 formats at bitrates up to 28 Mbps and frame rates up to 60p, giving creators flexibility for various production needs. It features a DIGIC DV 4 Image Processor, ensuring low-light performance and reduced noise even in challenging environments.
The C100 Mark II has dual SD card slots for relay or simultaneous recording, built-in ND filters (2, 4, and 6 stops), and a removable handle with XLR audio inputs for professional sound capture. Its OLED viewfinder, rotatable 3.5” LCD screen, and lightweight body make it a go-to for handheld shooting, while HDMI output allows for external recording or live monitoring.
Reliable, compact, and packed with pro features, the Canon EOS C100 Mark II is perfect for creators looking to step up their video production game.
Finally:
The Canon EOS C700 FF stands as a testament to Canon’s commitment to delivering cutting-edge technology for the cinematic arts. Its combination of high-resolution imaging, dynamic range, and versatile recording options makes it an indispensable tool for professionals aiming to achieve cinematic excellence.
